1964-65 GM A Body Chevelle El Camino GTO Tilt Floor Shift Steering Column - Steel

IDIDIT

Product images are representations and may not reflect actual product.

Click on image to zoom

Part# 1120640010

Retrofit 1964-1965 GM A Body Chevelle El Camino GTO Tilt Floor Shift Steering Column - Paintable Steel

MSRP $587.00

Accessories

Cruise Control Kit - Non-Computerized Engine

See Details

Horn Kit 1955-68 with Aluminum Ring & Washer

See Details

Installation Kit - 64-65 Chevelle/66 Chevelle CS CSRW

See Details

More Accessories

Description

This retrofit column is designed to fit your 1964 - 1965 GM A Body platform and does NOT require modification to your original vehicle to install. Simply remove your old column, saving your original under dash mount and floor mount and using one of our installation kits, you can install your new column in place of the old. Add an aftermarket wheel and the gripping surface of the new wheel will be in the same location as the original. Column comes standard with 8-position tilt, self-canceling turn signals, 4-way flashers, knobs & levers, 3 7/8" wiring plug, and a 3/4" 36 lower shaft.

Installation Kits

Kit Type	DELUXE KIT - ORIGINAL HARNESS			DELUXE KIT - AFTERMARKET HARNESS
Contents	Coupler/Shaft/Rag Joint/Flasher Kit			Coupler/Shaft/Rag Joint
Gearbox Input Shaft	Manual 3/4"-30	Manual 3/4"-36	Power 13/16"-36	Manual 3/4"-30	Manual 3/4"-36	Power 13/16"-36
1964*	3006001003	3006002003	*	3006001000	3006002000	*
1965	3006001003	3006002003	3006003003	3006001000	3006002000	3006003000
1966	3006004003	3006005003	3006006003	3006004000	3006005000	3006006000
1967-68	See AFTERMARKET HARNESS part numbers			3006007000	3006008000	3006009000
1969-72**	See AFTERMARKET HARNESS part numbers			3011007000	3011008000	3011009000

Kit Type	ECONO KIT - ORIGINAL HARNESS	ECONO KIT - AFTERMARKET HARNESS
Contents	Coupler/Flasher Kit	Coupler Only
1964*	3001001003	3000313449
1965	3001001003	3000313449
1966	3001002003	3000315249

* Power assisted manual gear boxes were used. Please refer to manual shaft sizes.
** 1969-72 kit contains U-Joint, Rag Joint and Collapsible Intermediate Shaft only

Retrofit Series

Deluxe Kit
This kit includes all the necessary parts you will need to install the column to the gearbox. All you need to know is the diameter of the gearbox input shaft and the number of splines.

Econo Kit
We had the builder on a budget in mind when we designed this kit. The original joint and intermediate shaft are used. The shaft will need to be cut and modified to match the 3/4" DD coupler. Due to age, the original rag joint may be worn so please double check to make sure it is in good condition. ididit, inc. always recommends replacing the rag joint.

Original Harness
For vehicles with an original factory harness, a 4-way flasher kit is included in your installation kit. This 4-way flasher kit will not only add safety to your vehicle, but will also convert your original wiring harness to the 3 7/8" plug found on your ididit column. (Only neccessary for 1964-66.)

Aftermarket Harness
Many aftermarket wiring companies offer replacement harnesses that incorporate a 4-way flasher unit as well as the flat 3 7/8" plug. If you are using one of these harnesses, a 4-way flasher kit is not necessary.

Specifications

Part# 1120640010
Brand IDIDIT
Fits Vehicle 1964 Chevrolet El Camino
Fits Vehicle 1964 Chevrolet Malibu
Fits Vehicle 1964 Oldsmobile Cutlass
Fits Vehicle 1964 Oldsmobile Vista Cruiser
Fits Vehicle 1964 Pontiac GTO
Fits Vehicle 1964 Pontiac Lemans
Fits Vehicle 1964 Pontiac Tempest
Fits Vehicle 1965 Chevrolet Chevelle
Fits Vehicle 1965 Chevrolet El Camino
Fits Vehicle 1965 Chevrolet Malibu
Fits Vehicle 1965 Oldsmobile Cutlass
Fits Vehicle 1965 Oldsmobile Vista Cruiser
Fits Vehicle 1965 Pontiac GTO
Fits Vehicle 1965 Pontiac Lemans
Fits Vehicle 1965 Pontiac Tempest
Self-Canceling Turn Signals Yes
Straight or Tilt 8-Position Tilt
4-Way Flashers Yes
Neutral Safety Switch No
Lower Shaft 3/4" 36
Knobs & Levers Included Yes
Lower Tube Diameter (in) 2 in
Horn Yes
Gear Shift Indicator Included No
Shifter Location Floor Shift
Floor Mount Included No
Telescoping Head No
Under Dash Mount Included No
Upper Shaft 69 to '94 GM Passenger Car
Upper Tube Diameter (in) 2 in
Wire Plug GM 3 7/8"
Collapsible No
Transmission Manual and Auto

Details

SKU: 1120640010
Availability: Available
Condition: New

Shipping Information

Requires Shipping: Item Requires Shipping
Weight: 13.6 lbs.
Package Dimensions: W8.0000” x H6.0000” x L44.0000”
