1962-73 Nova - Installation Kits

Retrofit Series

Deluxe Kit
This kit includes all the necessary parts you will need to install the column to the gearbox. All you need to know is the diameter of the gearbox input shaft and the number of splines.

Econo Kit
We had the builder on a budget in mind when we designed this kit. The original joint and intermediate shaft are used. The shaft will need to be cut and modified to match the 3/4" DD coupler. Due to age, the original rag joint may be worn so please double check to make sure it is in good condition. ididit, inc. always recommends replacing the rag joint.

Original Harness
For vehicles with an original factory harness, a 4-way flasher kit is included in your installation kit.  This 4-way flasher kit will not only add safety to your vehicle, but will also convert your original wiring harness to the 3 7/8" plug found on your ididit column.

Aftermarket Harness
Many aftermarket wiring companies offer replacement harnesses that incorporate a 4-way flasher unit as well as the flat 3 7/8" plug.  If you are using one of these harnesses, a 4-way flasher kit is not necessary.

INSTALLATION KITS (all the required components needed for flawless installation)

1962 3001001001
Econo Kit - Original Harness
Includes 3/4"-36 x 3/4"DD Coupler & Flasher Kit

1963-65 3001001002
Econo Kit - Original Harness
Includes 3/4"-36 x 3/4"DD Coupler & Flasher Kit

1966 3001001003
Econo Kit - Original Harness
Includes 3/4"-36 x 3/4"DD Coupler & Flasher Kit

1962-66 3000313449
Econo Kit - Aftermarket Harness
Includes 3/4"-36 x 3/4"DD Coupler

1967 3000313434
Econo Kit
Includes 3/4"-36 x 3/4"-36 Coupler

1969-73 3000053431
Deluxe Kit
Manual Gearbox Input Shaft: 3/4"-30
Includes 3/4"-36 x 3/4"-30 Rag Joint

1969-73 3000053434
Deluxe Kit
Manual Gearbox Input Shaft: 3/4"-36
Includes 3/4"-36 x 3/4"-36 Rag Joint

1969-73 3000053440
Deluxe Kit
Power Gearbox Input Shaft: 13/16"-36
Includes 3/4"-36 x 13/16"-36 Rag Joint
