1957 Chevy Tilt Floor Shift Steering Column - Brushed
Description
Considering the unwavering popularity of the 1955-56 Chevy, we would not be doing our jobs if we didn't offer a retrofit column for these legendary machines. Whether you're using the original manual gearbox, an aftermarket power box or converting to an all new rack and pinion, ididit has the column and the installation pieces you need to make this Classic even better.
Installation Kits
Kit Type | 605 BOX ORIGINAL HARNESS |
MANUAL BOX ORIGINAL HARNESS |
NO BOX SPECIFIED ORIGINAL HARNESS |
---|---|---|---|
Contents | Rag Joint/Floor Mount/Flasher Kit | Coupler/Floor Mount/Flasher Kit | Floor Mount/Flasher Kit |
1955 | 3005001005 | 3004002005 | 3008001005 |
1956 | 3005001006 | 3004002006 | 3008001006 |
1957 | 3005001007 | 3004002007 | 3008001007 |
Kit Type | 605 BOX AFTERMARKET HARNESS |
MANUAL BOX AFTERMARKET HARNESS |
NO BOX SPECIFIED AFTERMARKET HARNESS |
---|---|---|---|
Contents | Rag Joint/Floor Mount | Coupler/Floor Mount | Floor Mount |
1955-1957 | 3005001000 | 3004002000 | 2401400010 |
1955-57 Chevy Tri-Five - Floor Shift - Installation Kit
Retrofit Series
Original Harness
For vehicles with an original factory harness, a 4-way flasher kit is included in your installation kit. This 4-way flasher kit will not only add safety to your vehicle, but will also convert your original wiring harness to the 3 7/8" plug found on your ididit column.
Aftermarket Harness
Many aftermarket wiring companies offer replacement harnesses that incorporate a 4-way flasher unit as well as the flat 3 7/8" plug. If you are using one of these harnesses, a 4-way flasher kit is not necessary.
Floor Mount
A new floor mount is required for ALL installations. The original will not fit the ididit steering column.
Power Box
A rag joint is required if using a power box. The rag joint has 2 different functions. One, as a coupler between the lower shaft of the column and the input shaft of the gearbox. Two, as a vibration reducer which helps isolate pulsations commonly felt from the power steering pump.
Manual Box
If using the original box the shaft will need to be cut and modified and a coupler will need to be installed.
No Box Specified
If you are unsure whether you are using a box or a rack, give us a call and we can help determine what you have and what application will work the best.
Details
- 1070570030
- 1070570030
- IDIDIT
- 1957 Chevrolet Bel Air
- 1957 Chevrolet Nomad
- 8-Position Tilt
- Y
- Y
- N
- 1" DD
- 2 in
- N
- N
- N
- N
- 69 to '94 GM Passenger Car
- 2 in
- N
- Y
- Y
- GM 3 7/8"
- Floor Shift
- Manual and Auto
- Available
- New
Categories
- Retrofit Columns - Tilt Floor Shift
- Tilt Floor Shift
Shipping Information
- Item Requires Shipping
- 11.9 lbs.
- W8.0000” x H6.0000” x L44.0000”
